Technical parameters:
1.Rated Current：5.0A AMP
2.Contact Resistance：20 mΩ Max
3.Withstand Voltage：250 AC / DC
4.Insulation Resistance：1000 mΩ Min
5.WORKING TEMPERATURE:-55C~ +105°C
6.Contact Material：Phosphor Bronze
7.Contact Plating：Gold
8.MATERIAL:PBT BLACK UL94V-0.
9.Max. Processing Temp：245±5℃ for 30-60 seconds;245±5℃ for 10 seconds
10.THE SHAPE.SIZE AND POSITION OF THE CHARACTERSHOW THE OUTLIE THEY DON'T SHOW DETAILS
Product Description:
1. This connector is widely used in mobile phones, tablet PCs, navigators, LCD TVs, automobiles, aviation, smart wearable devices, etc.;
2. Inspection of this product Process is: IQC feed inspection -> into the warehouse -> before the on-line self-test -> IPQC inspection -> FQC final inspection -> OQC out of the cargo inspection
3. This product production process is: on-line inspection - > Cutting filament ribbons-->Assembly shell-->Electrical test-->Flatness test-->Positiveity test-->Appearance test-->FQC test-->into storage
