2FF SIM card connector

WL-SIM720-003

Product name: 1. 80H Push-Push SIM Card
Number: WL-SIM720-003
Specifications:Push-Push Type,1.8H,8+2 Pin,Shell Solder Tab 5.03mm,With Positioning Posts
INQUIRY EMAIL

Technical Parameters:

1.Housing: Lcp S475

2.Terminal:C5191-H

3.Shell: SUS304-H

4.Rated Voltage: 30V

5.Current Rating: 0.5A

6.Insulation Resistance:1000MQ Min.

7.Contact Resistance:100MΩ Max.

8.Withstanding Voltage: 500V DC For 1 Minutes.

9.Operating Temperature: -40°C~+85°C Humidity 80% R. H Max.

Product Description:

1. This Connector Is Widely Used In Mobile Phones, Tablet PCs, Navigators, LCD TVs, Automobiles, Aviation, Smart Wearable Devices, Etc.;
2. Inspection Of This Product Process Is: IQC Feed Inspection -> Into The Warehouse ->Before The On-Line Self-Test -> IPQC Inspection -> FQC Final Inspection -> OQC Out Of The Cargo Inspection
3. This Product Production Process is: On-Line Inspection - > Cutting Filament Ribbons-->Assembly Shell-->Electrical Test-->Flatness Test-->Positiveity Test-->Appearance Test-->FQC Test-->Into Storage

Drawing:
